SICK GM32 User Manual

71
8012704/YHS4/V2-0/2016-10 | SICK OPERATING INSTRUCTIONS | GM32
Subject to change without notice
TECHNICAL DATA 9
9.3.5 Bitmap Table “Failure”
9.3.6 Bitmap Table “Maintenance Request”
Bit No. Name Comment Bit No. Name Comment
0 EEPROM Bit=1: active 16 File config Bit=1: active
1 Spectro com. Bit=1: active 17 File conditions Bit=1: active
2 Zero com. Bit=1: active 18 File espec Bit=1: active
3 Extinction calc Bit=1: active 19 File cact Bit=1: active
4 Reference calc Bit=1: active 20 Visor com. Bit=1: active
5 IIR Filter Bit=1: active 21 Lamp com. Bit=1: active
6 Interpolation Bit=1: active 22 Spectro para. Bit=1: active
7 Filter com. Bit=1: active 23 Eval modul com. Bit=1: active
8 Mirror com. Bit=1: active 24 Purge air signal Bit=1: active
9 Visor fault Bit=1: active 25 Temp control com. Bit=1: active
10 Visor values Bit=1: active 26 Temp control out of range Bit=1: active
11 Zero adj. mc adj. Bit=1: active 27 Failure eval module Bit=1: active
12 Lamp fault Bit=1: active 28 MV failure activ Bit=1: active
13 Visor no signal Bit=1: active 29 Reserved Bit=1: active
14 Mirror adj. End Bit=1: active 30 Reserved Bit=1: active
15 File measval Bit=1: active 31 Reserved Bit=1: active
Table 29: Bitmap “Failure”
Bit No. Name Comment Bit No. Name Comment
0 Lamp performance Bit=1: active 16 Check Cycle cell empty Bit=1: active
1 Lamp minimum parameter Bit=1: active 17 Temp control voltage low Bit=1: active
2 Lamp 4Q max parameter Bit=1: active 18 Temp control lamp fan Bit=1: active
3 Data logging: writing data Bit=1: active 19 Temp control optic fan Bit=1: active
4 Data logging: open file Bit=1: active 20 Temp control spectro fan Bit=1: active
5 Temp. Extern Bit=1: active 21 Temp control electronic temp Bit=1: active
6 Flashcard missing Bit=1: active 22 Temp control spectro temp Bit=1: active
7 Logbook error Bit=1: active 23 Lamp performance limit Bit=1: active
8 IO com. Bit=1: active 24 Probe message Bit=1: active
9 IO error Bit=1: active 25 Reserved Bit=1: active
10 Spectro no answer Bit=1: active 26 Reserved Bit=1: active
11 Check Cycle span drift Bit=1: active 27 Reserved Bit=1: active
12 Check Cycle zero drift Bit=1: active 28 Reserved Bit=1: active
13 Check Cycle wavelength drift Bit=1: active 29 Reserved Bit=1: active
14 Check Cycle peak position Bit=1: active 30 Reserved Bit=1: active
15 Check Cycle peak width Bit=1: active 31 Reserved Bit=1: active
Table 30: Bitmap “Maintenance Request”
