SICK GM32 User Manual

66
8012704/YHS4/V2-0/2016-10 | SICKOPERATING INSTRUCTIONS | GM32
Subject to change without notice
9 TECHNICAL DATA
9.2.1 Sender/receiver unit
9.2.2 Reflector unit
9.2.3 Purge air fixture - sender/receiver unit
9.2.4 Purge air fixture - reflector unit
9.2.5 Connection unit
Description Analyzer unit of the measuring system
Operation Via integrated control unit
Dimensions (W x H x D) 315 mm x 580 mm x 359 mm
Weight 20 kg
Table 20: Technical data sender/receiver unit
Description Reflector unit with gas triple reflector
Process temperature
● ≤ +430 °C
● ≤ +650 °C (optional)
Versions for higher temperatures on request
Dimensions (W x H x D) 315 mm x 580 mm x 359 mm
Weight 9 kg
Table 21: Technical data reflector unit
Description Flange attachment with connections for purge air and external wiring
Dimensions (W x H x D) 320.9 mm x 360 mm x 220 mm (details see dimension drawings)
Weight 7 kg
Auxiliary gas connections Purge air
Built-in components
Temperature sensor PT1000
Flow monitor to monitor purge air feed
Table 22: Technical data purge air fixture - sender/receiver unit
Description Flange attachment with connections for purge air and external wiring
Dimensions (W x H x D) 320.9 mm x 360 mm x 220 mm (details see dimension drawings)
Weight 7 kg
Auxiliary gas connections Purge air
Built-in components Flow monitor to monitor purge air feed
Table 23: Technical data purge air fixture - reflector unit
Description
Serves for on-site connection of the power supply and of data and sig-
nal cables.
Analog outputs
2 outputs:
● 0/4 ... 22 mA, 500 Ω
● Modules freely selectable and extendable
Analog inputs
2 inputs
● 0/4 ... 22 mA, 100 Ω
● Modules freely selectable and extendable
Digital outputs
4 outputs:
● 48 V AC/DC, 0.5 A, 25 W
● Modules freely selectable and extendable
Table 24: Technical data connection unit
