SICK GM32 User Manual

57
8012704/YHS4/V2-0/2016-10 | SICK OPERATING INSTRUCTIONS | GM32
Subject to change without notice
CLEARING MALFUNCTIONS 7
7.3.2 Error messages
Initia-
tor
[1]
Text Classifi-
cation
Description Possible causes/remedy
[2]
System EEPROM Failure EEPROM parameters corrupted or not
compatible after software upgrade.
Software upgrade: Reset parameters.
Load saved parameters.
Defect: Reload backup.
Replace hardware, if possible.
Spectro com. Communication fault with spectrometer. Contact SICK Service.
Zero com. Communication fault with zero point
reflector.
Contact SICK Service.
Temp control
com.
Communication fault with temperature
control unit.
Contact SICK Service.
Visor com. Communication fault with visor module. Contact SICK Service.
Filter com. Communication fault with control filter
element.
Contact SICK Service.
Mirror com. Communication fault with mirror tracking. Contact SICK Service.
Lamp com. Communication fault with lamp electron-
ics.
Contact SICK Service.
LED com. Communication fault with LED electron-
ics.
Contact SICK Service.
Visor fault Error of visor signals. Signal distorted or
zero.
Check signals and parameters.
Visor values Visor signals outside the valid range. Hardware defect. Electronics not adjustable (ampli-
fication too high).
Visor no signal All 4Q signals below threshold parameter. Check alignment, reflector, contamination.
Lamp fault Lamp does not go on. Lamp is defective. Replace lamp, see “Checking
and replacing the desiccant cartridges”, page 50.
Mirror adj. End Mirror tracking has reached maximum
position.
Check alignment, see “Alignment check (automatic
optical alignment check; option)”, page 45.
Zero adj. mc
adj.
Beam tracking during adjustment not
possible.
Check alignment, see “Alignment check (automatic
optical alignment check; option)”, page 45.
Spectro para. No correct parameters saved in spec-
trometer.
Please contact SICK Customer Service.
Purge air sig-
nal
Digital input signals purge air error. Check purge air supply, see “Cleaning the purge air
unit”, page 53.
Temp control
out of range
Temperature regulation measurement
outside the valid range.
Excess temperature switch-off active for tempera-
tures > 70 °C. Switches back on automatically
when < 65 °C.
Extinction calc Error in extinction calculation. Please contact SICK Customer Service.
Reference calc Error in reference calculation.
IIR Filter Error during IIR filtering.
Interpolation Error in interpolation calculation.
Eval modul
com.
Error in communication with software
evaluation module.
File conditions Error during condition file access.
File espec Error during extinction file access.
File cact Error during lambda coefficient file
access.
File measval Error during measured value file access.
Table 17 Error messages
