7 CLEARING MALFUNCTIONS
Gas
compo-
nent
Bad Config.
(text)
Failure Error in calculation models. Please contact SICK Customer Service.
File I/O (text) Error in file system. Restart system.
If the error continues to exist:
Please contact SICK Customer Service.
Measurement
range x
Xtended Current measuring range x ( x = 1 .. 8) ---
Measurement
value out of
range
Uncer-
tain
Measured value outside calibration
range.
Check measured values for plausibility.
Measurement
value range
warning
Xtended Measurement beyond a warning thresh-
old defined during calibration.
Medium pres-
sure out of
range
Uncer-
tain
Sample gas pressure outside calibrated
range.
Check sample gas pressure.
Medium pres-
sure warning
Xtended Sample gas pressure beyond warning
threshold.
Medium tem-
perature out of
range
Uncer-
tain
Sample gas temperature outside cali-
brated range.
Check sample gas temperature.
Medium tem-
perature warn-
ing
Xtended Sample gas temperature beyond warning
threshold.
Absorption
range warning
Xtended Absorption in active measuring path
above warning threshold.
Standard setting of warning threshold:
1.8 extinction units.
Check:
- Window dirty see “Cleaning the window”, page 50.
- Dust content in sample gas too high?
- Sample gas concentration too high?
Absorption out
of range
Failure Absorption in active measuring path too
high.
Standard setting of error threshold: 2
extinction units.
Syntax error Error in concentration calculation. Contact SICK Service.
Processing
error
Numerical
(DivZero)
Numerical error in concentration calcula-
tion.
Numerical
(IppError)
Numerical
(MatSing)
OS error (text) Error in operating system. Restart system.
If the error continues to exist:
Please contact SICK Customer Service.
Spectr. resolu-
tion out of
range
Resolution of spectrometer wrong. Please contact SICK Customer Service.
Spectral evalu-
ation
Uncer-
tain
Error in calculation of spectra.
[1] System = SR-unit
CDH = purge air fixture on SR side
CDR = purge air fixture on reflector side
P = pressure sensor
T = temperature sensor
Gas component
[2] This Table also contains recommended solutions that can only be performed by specially trained personnel.
Initia-
tor
[1]
Text Classifi-
cation
Description Possible causes/remedy
[2]
Table 17 Error messages
