SICK GM32 User Manual

68
8012704/YHS4/V2-0/2016-10 | SICKOPERATING INSTRUCTIONS | GM32
Subject to change without notice
9 TECHNICAL DATA
Measured Value 5034 2 32 Bit float Input register Measuring value
Status 5036 1 16 Bit integer Input register Status
0)
Zero Point Value 5037 2 32 Bit float Input register Zero point
Span Point Value 5039 2 32 Bit float Input register Span point
Start of measuring range 5041 2 32 Bit float Input register min of range
End of measuring range 5043 2 32 Bit float Input register max of range
Regression coefficient C0 5045 2 32 Bit float Input register Offset
Regression coefficient C1 5047 2 32 Bit float Input register Slope
Regression coefficient C2 5049 2 32 Bit float Input register Correction factor
Table 25: Modbus component register (for the first 3 components)
