3PRODUCT DESCRIPTION
3 Product description
3.1 Product ID
3.1.1 Information on the housing
There is information printed on the housing identifying the sensor and its
electrical connection.
3.1.2 Type code
LFP x - x x x M x
1 2 3 4 5 6 7
Position Description
1 Product group
LFP (level sensors)
2 Probe length in mm
0025:
without probe
0200:
in 10 mm increments; rope probe in 1000 mm increments
4000:
4000 mm
3 Process connection/probe version
A: G ¾ A / single-rod probe 1.4404 interchangeable, 100 °C; 10 bar
B: ¾" NPT / single-rod probe 1.4404 interchangeable, 100 °C; 10 bar
E: G ¾ A / 3 mm rope probe, 1.4404 interchangeable, 100 °C; 10 bar
F: ¾" NPT / 3 mm rope probe, 1.4404 interchangeable, 100 °C; 10 bar
4 Housing, display/device connection
4: Plastic housing with display / M12 x 1 / 5-pin male connector
5: Plastic housing with display / M12 x 1 / 8-pin male connector
5 Application/design
B: Remote amplier; length of cable 1 m
C: Remote amplier; length of cable 2 m
D: Remote amplier; length of cable 3.3 m
N: Standard
6 Signal output
M: 4 mA ... 20 mA / 0 V ... +10 V reversible
7 Switching output
B: 1 x PNP + 1 x PNP/NPN
C: 1 x PNP + 3 x PNP/NPN
Not all variants of the type code can be combined with each other!
