SICK LFP CUBIC User Manual

OPERATING INSTRUCTIONS | LFP CUBIC 8019918/ZJA6 / 2017-07-20 | SICK AG
Subject to change without notice
6
1 ABOUT THIS DOCUMENT
1 About this document
1.1 Information on the operating instructions
These operating instructions provide important notes on how to use sensors from SICK AG.
Prerequisites for safe work are:
• Compliance with all safety notes and handling instructions supplied.
• Compliance with local work safety regulations and general safety regulations for
sensor applications.
The operating instructions are intended to be used by qualied personnel and electrical
specialists.
Note:
Read these operating instructions carefully before starting any work on the device,
in order to familiarize yourself with the device and its functions.
The instructions constitute an integral part of the product and are to be stored in the
immediate vicinity of the device so they remain accessible to sta at all times. Should
the device be passed on to a third party, these operating instructions should be handed
over with it.
These operating instructions do not provide information on operating the machine
in which the sensor is integrated. For information about this, refer to the operating
instructions of the particular machine.
1.2 Scope
These operating instructions serve to incorporate a sensor into a customer system.
Instructions are given by stages for all actions required.
These instructions apply to all available device variants of the sensor. For more detailed
information for the identication of the available device types, see “3.1.2 Type code”.
Available device variants are listed on the online product page:
b www.sick.com
Various device variants are used as examples for commissioning, based on the default
parameter settings for the relevant device.
Simplied device name in the document: In the following, the sensor is referred to in
simplied form as LFP. Exceptions occur where a distinction between device variants is
required due to dierent technical features or functions. In this case, the complete type
designation (e.g. LFP Cubic) is used.
1.3 Explanation of symbols
Warnings and important information in this document are labeled with symbols.
The warnings are introduced by signal words that indicate the extent of the danger.
These warnings must be observed at all times and care must be taken to avoid
accidents, personal injury, and material damage.
DANGER
… indicates a situation of imminent danger, which will lead to a fatality or serious
injuries if not prevented.
