Page #49 background image
OPERATING INSTRUCTIONS | LFP CUBIC 8019918 /ZJA6/ 2017-07-20 | SICK AG
Subject to change without notice
49
10OVERVIEW OF PARAMETERS
Parameter Description
QATYP Setting for the output signal.
4 mA ... 20 mA
0 V ... +10 V
Auto V = Qa operated with voltage output of 0 V … +10 V
Auto A = Qa operated with current output of
4 mA … 20 mA
Auto? = Automated signal detection based on
the existing load resistance
During a menu query, either 4 mA ... 20 mA or
0 V ... +10 V is displayed.
QAFAIL Output behavior as per NE43 in the event of a fault (func-
tion only available when current output has been selected
under QATYP).
3.5 mA = Analog current output is set to 3.5 mA in the
event of a fault.
21.5 mA = Analog current output is set to 21.5 mA in
the event of a fault.
SimCur See “8.4.6 Testing the conguration”.
SimVol See “8.4.6 Testing the conguration”.
DspVal Setting the display.
Distan = The display shows the distance in mm in
relation to the end of the probe.
QaPerc = The display shows the ll level in % in relation
to the QA analog output with the corresponding QAHIGH
and QALOW thresholds.
QaBarG = The display shows a bar graph in relation to
the QA analog output with the corresponding QAHIGH
and QALOW thresholds.
QaSign = The display shows the current QA output value
in mA or V.
QxSign = The display shows the output states.
Filter See “8.4.2 Filtering measured values”.
SimLev See “8.4.6 Testing the conguration”.
RstFac Resetting the set parameters to the factory settings.
EXPRT See “8.4.1 Expert mode”.
Lock See “8.4.11 Activating the display lock”.
Unit See “8.4.12 Selecting the display unit (millimeter/inch)”.
Oset See “8.4.13 Setting the oset”.
Mode See “8.4.5 Selection of evaluation method”.
MaxCol See “8.4.2 Filtering measured values”.
MeasMd Measuring mode.
HiSpd: max. length = 2,005 mm,
response time < 400 ms
HiAcc: max. length = 6,005 mm,
response time < 2,800 ms,
(more stable measured values, recommended for
liquids with low DKs and where TrsHld is < 70)
mode-1: not supported; deactivates current AutCal/
foam calibration
