OPERATING INSTRUCTIONS | LFP CUBIC 8019918/ZJA6 / 2017-07-20 | SICK AG
Subject to change without notice
48
10 OVERVIEW OF PARAMETERS
10 Overview of parameters
Parameter Description
Q1MENU, Q2MENU,
Q3MENU, Q4MENU
See “8.2 Conguring the switching outputs”.
SPx Switching point, switching output 1 or 2 or 3 or 4
(SPx > RPx).
Note: Not displayed if the switching output in the
OUx menu is set to Error or Window.
RPx Reset switching point, switching output 1 or 2 or 3 or 4.
Note: Not displayed if the switching output in the
OU2/3/4 menu is set to error or window.
FHx
FLx
Upper threshold (high) window function, switching
output 2/3/4 (FHx > FLx)
Lower threshold (low) window function, switching
output 2/3/4
Note: Not displayed if the switching output in the
OU2/3/4 menu is set to error or hysteresis.
OUx Switching output switching function.
Qx-Hno = Hysteresis function, normally open
Qx-Hnc = Hysteresis function, normally closed
Qx-Fno = Window function, normally open (function only
available for Q2/3/4)
Qx-Fnc = Window function, normally closed (function
only available for Q2/3/4)
Qx-Eno = Error signal, normally open (function only
available for Q2/3/4)
Qx-Enc = Error signal, normally closed (function only
available for Q2/3/4)
If Qx is used as an error signal, SPx/FHx and RPx/FLx are
hidden in the menu.
SimQx See “8.4.6 Testing the conguration”.
TYP2/3/4 Qx-PNP = Switching output in PNP circuit
Qx-NPN = Switching output in NPN circuit
Qx-Drv = Switching output executed in push/pull function
QAMENU See “8.3 Congure the analog output”.
QAHIGH Input of the lling level in mm for 20 mA/10 V signal
(QAHIGH > QALOW).
QALOW Input of the lling level in mm for 4 mA/0 V signal.
QAPOL The analog output signal can be inverted.
QA-Nrm = Analog output signal as congured
QA-Inv = Analog output signal is inverted:
QAHigh 4 mA/0 V and QALow 20 mA/10 V
