OPERATING INSTRUCTIONS | LFP CUBIC 8019918/ZJA6 / 2017-07-20 | SICK AG
Subject to change without notice
62
15 DIMENSIONAL DRAWINGS
15 Dimensional drawings
15.7.1 LFP Cubic with rod probe
104
(4.09)
22
(0.87)
L
IAE
IA
M
36 (1.42)
5
(0.20)
7 (0.28)
G 3/4 A
3/4" NPT
71
(2.80)
M 12 x1
43
(1.69)
50
(1.97)
33
(1.30)
L
20 (0.79)
15
22
(0.87)
126 (4.96)
G 3/4 A
3/4" NPT
IA
IAE
M
32
(1.26)
Mono-probe with coaxial tube
M Measuring range
L Probe length
IA Inactive area at process connection 25 mm
IAE Inactive area at probe end 10 mm
