Page #58 background image
OPERATING INSTRUCTIONS | LFP CUBIC 8019918/ZJA6 / 2017-07-20 | SICK AG
Subject to change without notice
58
14 TECHNICAL DATA
14.3 Mechanics/materials
Materials in contact with media: 1.4404, PTFE
Process connection G 3/4 A,
3/4'' NPT
Housing material Plastic PBT
Max. probe load ≤ 6 Nm
Enclosure rating IP67: EN 60529
Weight Max. 1.3 kg
Coaxial cable insulation PVC
14.4 Reference conditions
Container with diameter
1
m
Minimum distance to built-in components
>
300 mm
Distance from end of probe to tank bottom
> 15 mm
Air humidity
65% ±
20%
Temperature
+20 °C ±
5 °C
Pressure
1,013
mbar abs. ± 20 mbar
Medium Water, DK = 80
Centered installation of sensor
Container parameterization carried out
14.5 Ambient conditions
Ambient temperature, operation
1)
–20 °C … +60 °C
Ambient temperature, warehouse –40 °C ... +80 °C
1)
According to UL listing: degree of contamination 3 (UL61010-1: 2012-05); air humidity: 80%
at temperatures up to 31 °C; installation height: max. 3,000 m above sea level; only for indoor
applications
