10 OVERVIEW OF PARAMETERS
Parameter Description
Pulse See “8.4.5 Selection of evaluation method”.
AutCal See “7 Commissioning”.
TrsHld This value describes a factor which determines how strong
an echo has to be in order to be recognized by the device.
The value range lies between 20% and 500%. The default
is 100% in this case. Only shown if password entered.
• 20% = high sensitivity
• 100% = standard
• 500% = low sensitivity
AutoTn See “8.4.3 Automated adjustment of the interference
signal limit”.
CalRng Calibration range.
• Value range: 95 mm … 6005 mm
Range starting from the process connection in which
static interference signals (coupling sections, welds, spray
balls, etc.) are hidden during the AutCal process. During
the AutCal process, there must not be any medium in the
dened area of +200 mm.
See “8.4.8 Teaching in static interference signals”.
MaskZn See “8.4.4 Blanking the interference signals in the
masked zone”.
MaskTr See “8.4.4 Blanking the interference signals in the
masked zone”.
Reset Resets the value for AutCal.
Foam See “7.3 Foam commissioning (with factory settings)”.
CalEmp See “7.3 Foam commissioning (with factory settings)”.
CalMed See “7.3 Foam commissioning (with factory settings)”.
Limit Limit between foam and uid.
• Range: 20 to 100%
• Factory setting: 90%
• Medium surface: 90%
• Foam surface: < 90%
When measuring the foam surface, it may be necessary to
reduce the limit. If the sensor displays a limit value that is
too low, it is necessary to reduce the limit.
Reset Resets the values for CalEmp and CalMed.
Probe Special settings.
Length • See “7.3 Foam commissioning (with factory settings)”
(LFP Cubic).
CblLen See “8.4.10 Changing the coaxial cable length”.
Type Choosing between rod and rope.
Info Sensor information.
FrmVer Shows the rmware version.
SerNo Shows the serial number.
CalSta Displays the status of the tank calibration.
• Pulse = AutCal (calibrated), NoCal (not calibrated)
• Foam = FomCal (calibrated), CalMis (not calibrated)
AppTag Measuring point name, can only be described via IO-Link.
