10.2.10 Set LMS output
The message sets the outputs on the LMS, if the output is configured to SOPAS command
in SOPAS ET.
PROJECT TREE, LMS…, PARAMETER, NETWORK/INTERFACES/IOS, DIGITAL OUTPUTS.
Important If the status of several outputs is to be set, then the message must be sent separately for
each output.
Request
Message structure: sMN mDOSetOutput Status output
Answer
Message structure: sAN mDOSetOutput ErrorCode
Example
Request: <STX>sMN{SPC}mDOSetOutput{SPC}0{SPC}1<ETX>
Answer: <STX>sAN{SPC}mDOSetOutput{SPC}1<ETX>
Message part Description Variable type Length
(byte)
Value range
Type of command Request (SOPAS method by name) string 3 sMN
Command Set output string 12 mDOSetOutput
Output Output number uint_8 1 0 output 1
1 output 2
2 output 3
3 output 4
4 output 5
5 output 6
Status State of the output uint_8 1 0 inactive
1 active
Message syntax XXI: Request “Set LMS output”
Message part Description Variable type Length
(byte)
Value range
Type of command Answer (SOPAS answer) string 3 sAN
Command Set output string 12 mDOSetOutput
ErrorCode The command has been accepted
if the error code 1 is returned.
bool_1 1 0 error
1 no error
Message syntax XXII: Answer to the “Set LMS output” request
