SICK MAX Series

Electrical data
Supply voltage ripple < 1% p-p
Power consumption:
12 VDC voltage signal ≤ 0.5 W
24 VDC voltage signal ≤ 0.5 W
24 VDC current signal / PWM ≤ 1.0 W
Current consumption:
12 VDC voltage signal ≤ 30 mA
24 VDC voltage signal ≤ 20 mA
24 VDC current signal / PWM ≤ 40 mA
Load resistance:
Voltage signal RL ≥ 10 kΩ
Current signal 100 Ω < RL < 500 Ω
Switch-on current:
12 VDC supply voltage 2.5 A / 50 µsec typical
24 VDC supply voltage 5.0 A / 50 μsec typical
Over voltage protection ISO 16750-2: ≤ + 36 VDC on all poles
Reverse polarity protection ISO 16750-2: on all poles
Insulation resistance ISO 16750-2: Riso ≥ 10 MΩ, 60 sec
Dielectric strength ISO 16750-2: 500 VDC (0 VDC to housing)
Dimensions
Size MAX48: 48f7 mm (for installation in a 48H8 clearance)
MAX30: 31f7 mm (for installation in a 31H8 clearance)
Unusable range:
Null zone (zero point) MAX48: 30.0 mm
MAX30: 19.5 mm
Damping (end point) 30.0 mm/ 36.0 mm/ 63.0 mm (depending on type)
Pressure pipe Ø 7 mm or 10 mm (depending on type)
O-ring MAX48: Ø 40.87 x 3.53 mm
MAX30: Ø 24.99 x 3.53 mm
Support ring MAX48: Ø 42.6 x 48 x 1.4 mm
MAX30: Ø 31 x 25.8 x 1.4 mm
M12 flange EN 61076-2-101 DM 20 x 20 mm - 14 mm hole pattern
3-wire cable Ø 5.2 mm, 3 x 0.32 mm² (AWG22),
stripped 300 … 10,000 mm (depending on type)
Material
Pressure pipe Stainless steel 1.4306, AISI 304L
Electronics housing Stainless steel 1.4305, AISI 303
O-ring NBR 70
Support ring PTFE
M12 male connector insert Glass fiber reinforced polyamide, nickel-/gold-plated brass contacts
M12 flange Stainless steel with O-ring (NBR70)
Cable PUR cable sheath / PVC strand
10 TECHNICAL DATA
44
