7SR210 Settings Guide
Unrestricted ©2018 Siemens Protection Devices Limited Page 59 of 61
3.10.2. Waveform Storage
Description Range Default
Gn P/F Trig Storage
Select which elements trigger a waveform record
Combination of ( 51-1, 51-2, 50-1, 50-2 ) 51-1, 51-2, 50-1,
50-2
Gn E/F Trig Storage
As Above
Combination of ( 51N-1, 51N-2, 50N-1,
50N-2, 51G-1, 51G-2, 50G-1, 50G-2 )
51N-1, 51N-2,
50N-1, 50N-2,
51G-1, 51G-2,
50G-1, 50G-2
Gn SEF/REF Trig Storage
As Above
Combination of ( 51SEF-1, 51SEF-2,
50SEF-1, 50SEF-2, 64H )
51SEF-1,
51SEF-2,
50SEF-1,
50SEF-2, 64H
Gn Misc Current Storage
As Above
Combination of ( 46IT, 46DT, 37-1, 37-2,
49 Trip, 49 Alarm, 37G-1, 37G-2 )
--------
Gn AFD Trig Storage
As Above
Combination of ( AFD-1, AFD-2, AFD-3,
AFD-4, AFD-5, AFD-6)
------
Pre-trigger Storage
Select Percentage of waveform record stored before
the fault is triggered
10, 20, 30, 40, 50, 60, 70, 80, 90 20 %
Record Duration
Select waveform record duration
10 Rec x 1 Sec, 5 Rec x 2 Sec, 2 Rec x 5
Sec, 1 Rec x 10 Sec
10 Rec x 1 Sec
Trigger Waveform
Trigger waveform storage
Clear Waveforms
Clear all stored waveform records
3.10.3. Fault Storage
Description Range Default
Gn Max Fault Rec Time
Maximum time Fault record information will be stored and
classed as same fault
0, 1 ... 59900, 60000 2000 ms
Clear Faults
Clear all stored fault records
3.10.4. Event Storage
Description Range Default
Clear Events
Clear all stored event records
Data Log
Selects whether the Data Logger is enabled
