7SR21 & 7SR22 Performance Specification
Unrestricted © 2013 Siemens Protection Devices Limited Page 55 of 68
2.25 50 AFD ARC Flash Detector
(Refer to 7XG31 Technical Manual for performance characteristics)
2.25.1 Reference
Parameter Value
50 AFD Setting 1, 2,...10 xIn
2.25.2 Operate and Reset Level
Attribute Value
I
op
Operate level
100 % Is, ± 10 %
Transient overreach (X/R £ 100) £ -30 %
Reset level
³ 95 % I
op
Repeatability
± 5 %
2.25.3 Operate and Reset Time
Attribute Value
t
basic
50AFD Overcurrent operate time 10 ms – 16 ms
t
op
AFD Zone operate time (Flash & 50AFD) 15 ms – 25 ms
Repeatability
± 10 ms
Disengaging time < 50 ms
