7SR21 & 7SR22 - Installation Guide
Unrestricted Page 30 of 36 ©2018 Siemens Protection Devices Limited
7.2 Typical Connection: 7SR22 Directional OC/EF and NVD
Figure 7.2-1 7SR22 Applied to Transformer Incomer Including HV NVD Protection
