Siemens Argus 7SR21 User Manual

7SR220 Settings Guide
Unrestricted Page 76 of 107 © 2013 Siemens Protection Devices Limited
3.13. Output Config
3.13.1. Output Matrix
Description Range Default
Protection Healthy
Relays selected are energised whilst relay self-monitoring
does NOT detect any hardware or software errors and DC
Supply is healthy. A changeover contact or normally closed
contact may be used to generate Protection Defective from this
output
Combination of ( BO1, BO2, BO3,
BO4, BO5, BO6, BO7, BO8, BO9,
BO10, BO11, BO12, BO13, BO14,
L1, L2, L3, L4, L5, L6, L7, L8, L9,
L10, L11, L12, L13, L14, V1, V2,
V3, V4, V5, V6, V7, V8, V9, V10,
V11, V12, V13, V14, V15, V16 )
BO1
Active Setting Grp 1
Combination of ( BO1, BO2, BO3,
BO4, BO5, BO6, BO7, BO8, BO9,
BO10, BO11, BO12, BO13, BO14,
L1, L2, L3, L4, L5, L6, L7, L8, L9,
L10, L11, L12, L13, L14, V1, V2,
V3, V4, V5, V6, V7, V8, V9, V10,
V11, V12, V13, V14, V15, V16 )
Grp 1
Active Setting Grp 2
Combination of ( BO1, BO2, BO3,
BO4, BO5, BO6, BO7, BO8, BO9,
BO10, BO11, BO12, BO13, BO14,
L1, L2, L3, L4, L5, L6, L7, L8, L9,
L10, L11, L12, L13, L14, V1, V2,
V3, V4, V5, V6, V7, V8, V9, V10,
V11, V12, V13, V14, V15, V16 )
Active Setting Grp 3
Combination of ( BO1, BO2, BO3,
BO4, BO5, BO6, BO7, BO8, BO9,
BO10, BO11, BO12, BO13, BO14,
L1, L2, L3, L4, L5, L6, L7, L8, L9,
L10, L11, L12, L13, L14, V1, V2,
V3, V4, V5, V6, V7, V8, V9, V10,
V11, V12, V13, V14, V15, V16 )
Active Setting Grp 4 Combination of ( BO1, BO2, BO3,
BO4, BO5, BO6, BO7, BO8, BO9,
BO10, BO11, BO12, BO13, BO14,
L1, L2, L3, L4, L5, L6, L7, L8, L9,
L10, L11, L12, L13, L14, V1, V2,
V3, V4, V5, V6, V7, V8, V9, V10,
V11, V12, V13, V14, V15, V16 )
Active Setting Grp 5 Combination of ( BO1, BO2, BO3,
BO4, BO5, BO6, BO7, BO8, BO9,
BO10, BO11, BO12, BO13, BO14,
L1, L2, L3, L4, L5, L6, L7, L8, L9,
L10, L11, L12, L13, L14, V1, V2,
V3, V4, V5, V6, V7, V8, V9, V10,
V11, V12, V13, V14, V15, V16 )
Active Setting Grp 6 Combination of ( BO1, BO2, BO3,
BO4, BO5, BO6, BO7, BO8, BO9,
BO10, BO11, BO12, BO13, BO14,
L1, L2, L3, L4, L5, L6, L7, L8, L9,
L10, L11, L12, L13, L14, V1, V2,
V3, V4, V5, V6, V7, V8, V9, V10,
V11, V12, V13, V14, V15, V16 )
Active Setting Grp 7 Combination of ( BO1, BO2, BO3,
BO4, BO5, BO6, BO7, BO8, BO9,
BO10, BO11, BO12, BO13, BO14,
L1, L2, L3, L4, L5, L6, L7, L8, L9,
L10, L11, L12, L13, L14, V1, V2,
V3, V4, V5, V6, V7, V8, V9, V10,
V11, V12, V13, V14, V15, V16 )
Active Setting Grp 8 Combination of ( BO1, BO2, BO3,
BO4, BO5, BO6, BO7, BO8, BO9,
BO10, BO11, BO12, BO13, BO14,
L1, L2, L3, L4, L5, L6, L7, L8, L9,
L10, L11, L12, L13, L14, V1, V2,
V3, V4, V5, V6, V7, V8, V9, V10,
V11, V12, V13, V14, V15, V16 )
