Siemens Argus 7SR21 - 51 Sef-2; 51 Sef-3

7SR220 Settings Guide
Unrestricted Page 28 of 107 © 2013 Siemens Protection Devices Limited
Description Range Default
Gn 51SEF-1 Char
Selects characteristic curve to be IEC or ANSI IDMTL or DTL
DTL, IEC-NI, IEC-VI, IEC-EI, IEC-
LTI, ANSI-MI, ANSI-VI, ANSI-EI
IEC-NI
Gn 51SEF-1 Time Mult (IEC/ANSI)
Time multiplier (applicable to IEC and ANSI curves but not
DTL selection)
0.025, 0.03 ... 1.595, 1.6 , 1.7 ...
4.9, 5, 6 ... 100
1
Gn 51SEF-1 Delay (DTL)
Delay (applicable only when DTL is selected for characteristic)
0, 0.01 ... 19.99, 20 5 s
Gn 51SEF-1 Min Operate Time
Minimum operate time of element.
0, 0.01 ... 19.99, 20 0 s
Gn 51SEF-1 Follower DTL
Additional definite time added after characteristic time
0, 0.01 ... 19.99, 20 0 s
Gn 51SEF-1 Reset
Selects between an ANSI decaying reset characteristic or DTL
reset
(ANSI) Decaying, 0 ... 59, 60 0 s
Gn 51SEF-1 VTS Action
Selects whether 51SEF-1 element is blocked or made non-
directional when VTS operates
Off, Inhibit, Non-Dir Off
3.4.6.2. 51SEF-2
Description Range Default
Gn 51SEF-2 Element
Selects whether the 51SEF-2 IDMTL derived Earth Fault
element is enabled
Disabled, Enabled Disabled
Gn 51SEF-2 Dir. Control
Selects whether 51SEF-2 element is non-directional, forward
or reverse
Non-Dir, Forward, Reverse Non-Dir
Gn 51SEF-2 Setting
Pickup level
0.005, 0.006 ... 0.995, 1 0.2 xIn
Gn 51SEF-2 Char
Selects characteristic curve to be IEC or ANSI IDMTL or DTL
DTL, IEC-NI, IEC-VI, IEC-EI, IEC-
LTI, ANSI-MI, ANSI-VI, ANSI-EI
IEC-NI
Gn 51SEF-2 Time Mult (IEC/ANSI)
Time multiplier (applicable to IEC and ANSI curves but not
DTL selection)
0.025, 0.03 ... 1.595, 1.6 , 1.7 ...
4.9, 5, 6 ... 100
1
Gn 51SEF-2 Delay (DTL)
Delay (applicable only when DTL is selected for characteristic)
0, 0.01 ... 19.99, 20 5 s
Gn 51SEF-2 Min Operate Time
Minimum operate time of element.
0, 0.01 ... 19.99, 20 0 s
Gn 51SEF-2 Follower DTL
Additional definite time added after characteristic time
0, 0.01 ... 19.99, 20 0 s
Gn 51SEF-2 Reset
Selects between an ANSI decaying reset characteristic or DTL
reset
(ANSI) Decaying, 0 ... 59, 60 0 s
Gn 51SEF-2 VTS Action
Selects whether 51SEF-2 element is blocked or made non-
directional when VTS operates
Off, Inhibit, Non-Dir Off
3.4.6.3. 51SEF-3
Description Range Default
Gn 51SEF-3 Element
Selects whether the 51SEF-3 IDMTL derived Earth Fault
element is enabled
Disabled, Enabled Disabled
