7SR220 Settings Guide
Unrestricted Page 102 of 107 © 2013 Siemens Protection Devices Limited
3.14.1. CB Counters
Description Range Default
Gn CB Total Trip Count
Selects whether the CB Total Trip Count counter is enabled
Disabled, Enabled Disabled
Gn CB Total Trip Count Target
Selects the number of CB trips allowed before CB Total Trip
Count counter output operates
0, 1 ... 9999, 10000 100
Gn CB Total Trip Count Reset
Resets CB Total Trip Count counter
Gn CB Total Trip Manual Open
Selects whether the CB Total Trip Manual Open is enabled
Disabled, Enabled Disabled
Gn CB Phase Trip Counters
Selects whether the CB Phase Trip Counters is enabled
Disabled, Enabled Disabled
Gn CB Ph A Trip Count Target
Selects the number of CB trips allowed before CB Ph A Trip
Count counter output operates
0, 1 ... 9999, 10000 100
Gn CB Ph B Trip Count Target
Selects the number of CB trips allowed before CB Ph B Trip
Count counter output operates
0, 1 ... 9999, 10000 100
Gn CB Ph C Trip Count Target
Selects the number of CB trips allowed before CB Ph C Trip
Count counter output operates
0, 1 ... 9999, 10000 100
Gn CB E/F Trip Count Target
Selects the number of CB trips allowed before CB E/F Trip
Count counter output operates
0, 1 ... 9999, 10000 100
Gn CB Delta Trip Count
Selects whether the CB Delta Trip Count counter is enabled
Disabled, Enabled Disabled
Gn CB Delta Trip Count Target
Selects the number of CB trips allowed before CB Delta Trip
Count counter output operates
0, 1 ... 9999, 10000 100
Gn CB Delta Trip Count Reset
Resets CB Delta Trip Count counter
Gn CB Count To AR Block
Selects whether the CB Count To AR Block counter is enabled
Disabled, Enabled Disabled
Gn CB Count To AR Block Target
Selects the number of CB trips allowed before CB Count To
AR Block counter output operates. While count is above target
the Autorecloser will only perform 1 x Delayed Shot and
Lockout
0, 1 ... 9999, 10000 100
Gn CB Count To AR Block Reset
Resets CB Count To AR Block counter
Gn CB Freq Ops Count
Selects whether the CB Frequent Operations Counter is
enabled
Disabled, Enabled Disabled
Gn CB Freq Ops Count Target
Selects the number of CB trips allowed before CB Frequent
Operations Counter output operates. While count is above
target the Autorecloser will only perform 1 x Delayed Shot and
Lockout
0, 1 ... 9999, 10000 10
Gn CB Freq Ops Count Reset
Resets CB Frequent Operations Counter
3.14.2. I^2T CB Wear
Description Range Default
