7SR220 Settings Guide
Unrestricted ©2018 Siemens Protection Devices Limited Page 73 of 107
3.12.3. Binary Input Config (Variants may differ)
Description Range Default
Inverted Inputs
Selects which inputs pickup when voltage is removed.
Combination of ( 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13 )
-------------
BI 1 Pick-up Delay
Delay on pickup of DC Binary Input 1
0, 0.005 ... 14300, 14400 0.02 s
BI 1 Drop-off Delay
Delay on dropoff of DC Binary Input 1
0, 0.005 ... 14300, 14400 0 s
BI 2 Pick-up Delay
Delay on pickup of DC Binary Input 2
0, 0.005 ... 14300, 14400 0.02 s
BI 2 Drop-off Delay
Delay on dropoff of DC Binary Input 2
0, 0.005 ... 14300, 14400 0 s
BI 3 Pick-up Delay
Delay on pickup of DC Binary Input 3
0, 0.005 ... 14300, 14400 0.02 s
BI 3 Drop-off Delay
Delay on dropoff of DC Binary Input 3
0, 0.005 ... 14300, 14400 0 s
BI 4 Pick-up Delay
Delay on pickup of DC Binary Input 4
0, 0.005 ... 14300, 14400 0.02 s
BI 4 Drop-off Delay
Delay on dropoff of DC Binary Input 4
0, 0.005 ... 14300, 14400 0 s
BI 5 Pick-up Delay
Delay on pickup of DC Binary Input 5
0, 0.005 ... 14300, 14400 0.02 s
BI 5 Drop-off Delay
Delay on dropoff of DC Binary Input 5
0, 0.005 ... 14300, 14400 0 s
BI 6 Pick-up Delay
Delay on pickup of DC Binary Input 6
0, 0.005 ... 14300, 14400 0.02 s
BI 6 Drop-off Delay
Delay on dropoff of DC Binary Input 6
0, 0.005 ... 14300, 14400 0 s
BI 7 Pick-up Delay
Delay on pickup of DC Binary Input 7
0, 0.005 ... 14300, 14400 0.02 s
BI 7 Drop-off Delay
Delay on dropoff of DC Binary Input 7
0, 0.005 ... 14300, 14400 0 s
BI 8 Pick-up Delay
Delay on pickup of DC Binary Input 8
0, 0.005 ... 14300, 14400 0.02 s
BI 8 Drop-off Delay
Delay on dropoff of DC Binary Input 8
0, 0.005 ... 14300, 14400 0 s
BI 9 Pick-up Delay
Delay on pickup of DC Binary Input 9
0, 0.005 ... 14300, 14400 0.02 s
BI 9 Drop-off Delay
Delay on dropoff of DC Binary Input 9
0, 0.005 ... 14300, 14400 0 s
BI 10 Pick-up Delay
Delay on pickup of DC Binary Input 10
0, 0.005 ... 14300, 14400 0.02 s
BI 10 Drop-off Delay
Delay on dropoff of DC Binary Input 10
0, 0.005 ... 14300, 14400 0 s
BI 11 Pick-up Delay
Delay on pickup of DC Binary Input 11
0, 0.005 ... 14300, 14400 0.02 s
BI 11 Drop-off Delay
Delay on dropoff of DC Binary Input 11
0, 0.005 ... 14300, 14400 0 s
