Clinitek Advantus Operator’s Guide 79

System Configuration

Install the Waste Bin Liner

1. Take a waste bin liner from the pack delivered with the analyzer.

2. Place the liner into the waste bin.

Figure 28 Install the Waste Bin Liner
