5.5.13 Assigning I/O addresses to the NCU machine data
Procedure
To
enter addresses which have been configured in the TIA Portal in the machine data, proceed
as follows:
1. Check in the TIA Portal which addresses you have assigned to the I/O modules
(see Configuring IO modules or drive telegrams (Page 106)).
2. Transfer the addresses to the following machine data (e.g. via SINUMERIK Operate):
MD Identifier Description Concerns the mod‐
ule type
105
00
$MN_DPIO_LOGIC_AD‐
DRESS_IN
Logical slot address of the PROFIBUS/
PROFINET I/O
Input module
105
01
$MN_DPIO_RANGE_LENG
TH_IN
Length of the PROFIBUS/PROFINET I/
O range
Input module
105
10
$MN_DPIO_LOGIC_AD‐
DRESS_OUT
Logical slot address of the PROFIBUS/
PROFINET I/O
Output module
105
11
$MN_DPIO_RANGE_LENG
TH_OUT
Length of the PROFIBUS/PROFINET I/
O range
Output module
Use machine data with the same index in order to enter the address and the associated
address length of a module. Use, for example, for the address of an input module,
MD10500[1] and for the address length of the same module MD10501[1].
Example
The following example compares the configuration in the TIA Portal and the compared values
in the machine data:
Table 5-1 Configuring in the TIA Portal with five IO modules
Module Address
2AI U HS 1020…1023
2AO U HS 1020…1023
4DI 24 VDC HF 1016.0…1016.3
4DI 24 VDC HF 1018.0…1018.7
8DO 24 VDC / 0.5 A HF 1018.0…1018.7
Configuring networks
5.5 Configuring PROFINET IO with IRT
SINUMERIK STEP 7 Toolbox V15.1
Configuration Manual, 12/2018, A5E46279635B AA 113
