Software option Purpose
SI Axis/Spindle Additional license for one axis/spindle, multiple licensing in order to be able to use
further axes/spindles.
SI Axis/Spindle
package
Additional license for 15 axes/spindles, multiple licensing in order to be able to use
further axes/spindles.
SI-Connect Make more than three FSEND and three FRECV connections available.
Depending on the functionality used, you must license the appropriate software options and set
in the machine data:
●
MD19120 $MN_NUM_SAFE_AXES: Number of SI axes/spindles
● MD19122 $MN_NUM_SPL_IO: Number of SPL I/Os
1 = 4 SPL I/O or SI-Basic software option
2 = 64 SPL I/O or SI-Comfort software option
3 = 192 SPL I/O or SI-High Feature software option
● MD19510 $MN_SAFE_FUNCTION_MASK: Number of FSEND and FRECV connections
SI-Connect software option: Bit 0 = 1
See also:
● SINUMERIK 840D sl Basic Software and Operating Software Commissioning Manual,
Section SINUMERIK Operate (IM9).
● Function Manual, SINUMERIK Safety Integrated
10.6.3 Software options for Safety Integrated plus (F-PLC)
For the use of Safety Integrated plus (F-PLC), you require in addition to the license for SIMATIC
STEP 7 Safety Advanced (TIA Portal), the appropriate software options for the RT function:
Table 10-3 Software options for the use of Safety Integrated plus (F-PLC)
Software option Purpose
SINUMERIK Safety Integrated plus
/SI logic
Activate the F-PLC in SINUMERIK 840D sl in order to process
the fail-safe sensors and actuators in an F-program.
SINUMERIK Safety Integrated plus
/SI axis/spindle
Use the motion control functions of the SINAMICS Integrated in
the SINUMERIK Safety Integrated plus (F-PLC) mode.
License for one axis/spindle, multiple licensing in order to be
able to use further axes/spindles.
SINUMERIK Safety Integrated plus
/SI multi-axis package
Use the motion control functions of the SINAMICS Integrated in
the SINUMERIK Safety Integrated plus (F-PLC) mode.
License for any number of axes/spindles.
Depending on the functions used, you must license the appropriate software options and set in
the machine data:
●
MD19500 $MN_SAFE_PLC_LOGIC: Safety Integrated plus /SI-Logic basic option
● MD19121 $MN_NUM_DRIVEBASED_SAFE_AXES: Number of axes/spindles in Safety
Integrated plus (F-PLC) mode
Safety configuration
10.6 Licensing
SINUMERIK STEP 7 Toolbox V15.1
186 Configuration Manual, 12/2018, A5E46279635B AA
