in the SINAMICS S120/S150 List Manual (https://support.industry.siemens.com/cs/document/
109739998/).
Telegram Function diagram
30…31 2915
901…903 2916
6.7.4 Telegrams for SIC/SCC communication
The standard telegram configuration (Page 116) of a SINUMERIK NCU with Safety Integrated
plus (F-PLC) uses the following telegram types for SIC/SCC communication:
Table 6-6 Telegrams for control via PROFIsafe and SIC/SCC (PROFIdrive)
Profile Designation Purpose
PROFIdrive (SIC/SCC) SIEMENS telegram 701 Manufacturer-specific telegram for SIC/SCC communication.
With SINUMERIK, SIC/SCC communication only takes place
via telegram 701.
For the purpose of implementing a user-defined telegram configuration (Page 121), you can
also configure telegram 700.
Further information
You will find a brief description of all configurable telegram types in the TIA Portal in the tooltip
for the telegram. Detailed information can be found in the respective function block diagrams
in the SINAMICS S120/S150 List Manual (https://support.industry.siemens.com/cs/document/
109739998/).
Telegram Function diagram
700…701 2423
Configuring telegrams and drive units
6.7 Available telegram types
SINUMERIK STEP 7 Toolbox V15.1
132 Configuration Manual, 12/2018, A5E46279635B AA
