Page #44 background image
3.6 Creating SINUMERIK PLC archives
3.6.1
Creating a SINUMERIK PLC archive
Introduction
Unlike TIA Portal project archives (*.zap*), SINUMERIK PLC archives (*.arc) contain
precompiled commissioning data that you can import directly to the NCU (e.g. with SINUMERIK
Operate).
A SINUMERIK archive offers the following possibilities:
Direct image of the data of a PLC taken into operation in a file
Simplification of the series commissioning
Commissioning of the PLC with the SINUMERIK archive directly on the NCU without using
a PG/PC, TIA Portal or STEP 7
Transfer of the data to the NCU without establishing an online connection to the actual
hardware
SINUMERIK archives (*.arc) have nothing in common with TIA Portal project archives (*.zap*).
TIA Portal project archives are compressed files, each of which contains a complete project,
including the complete folder structure of the project. (See: Online help, keyword "TIA Portal
project archive").
You can create a PLC archive with the SINUMERIK Toolbox and load it to the NCU (e.g. with
SINUMERIK Operate) in order to simplify the actual commissioning.
You can create the following SINUMERIK archives:
Archive type Command in the TIA
Portal
Data included
PLC hardware upgrade ar‐
chive (Page 48
)
Only hardware...
Hardware data (SDB) of the PLC
PLC commissioning ar‐
chive (Page 50
)
Hardware and all pro‐
gram blocks...
Hardware data (SDB) of the PLC
Program blocks of the PLC
Hardware data (SDB) of the CP
PLC reload archive
(Page 52)
Selected program
blocks...
Program blocks of the PLC
Note
Editing SINUMERIK archives (.arc)
After you have created a SINUMERIK archive, you can open and edit it with various tools.
See: External tools for SINUMERIK archives
(Page 48)
Configuring the NCU
3.6 Creating SINUMERIK PLC archives
SINUMERIK STEP 7 Toolbox V15.1
44 Configuration Manual, 12/2018, A5E46279635B AA
