10.6 Licensing
10.6.1
Overview
The integrated safety functions of SINUMERIK Safety Integrated are used in the machine tools
sector. They are integrated with two channels in the NC, the drive and the internal PLC, and are
used to monitor speed, standstill and position. Such monitoring is necessary if the danger zone
of the machines and systems is not blocked off.
During operation, the integrated safety functions provide effective operator protection as well
as protection of tools, materials and machines.
In the TIA Portal, you can select one of three modes in conjunction with the SINUMERIK:
Mode Requirement
SINUMERIK Safety Inte‐
grated not active
-
Safety Integrated (SPL)
● SIMATIC STEP 7 Safety Advanced option package (no license
required: SIMATIC STEP 7 Safety Advanced without license
corresponds to the F-configuration tool from STEP 7 V5.x)
●
Appropriate software option for SPL
Safety Integrated plus (F-
PLC)
● NCU V4.7 or higher
●
SIMATIC STEP 7 Safety Advanced option package
● License for SIMATIC STEP 7 Safety Advanced
● Appropriate software option for F-PLC
Refer to Section Changing the Safety Integrated mode for a description of how to set the Safety
Integrated mode.
10.6.2
Software options for Safety Integrated (SPL)
To configure SINUMERIK Safety Integrated (SPL), SIMATIC STEP 7 Safety Advanced (TIA
Portal) without license suffices. (SIMATIC STEP 7 Safety Advanced without license
corresponds to the F-configuration tool from STEP 7 V5.x)
To use the configuring in SINUMERIK Operate, you require the appropriate software options:
Table 10-2 Software options for use of Safety Integrated (SPL)
Software option Purpose
SI Basic Activate SPL
Contains a license for one axis/spindle, up to four SPL I/O
SI Comfort Activate SPL
Contains a license for one axis/spindle, up to 64 SPL I/O
SI High Feature Activate SPL
Contains a license for one axis/spindle, up to 192 SPL I/O
Safety configuration
10.6 Licensing
SINUMERIK STEP 7 Toolbox V15.1
Configuration Manual, 12/2018, A5E46279635B AA 185
