Address Icon Description
DB1002 ISM_TS Interface between user program and operating software, contains
signals for spindle temperature sensors.
DB1071 TMLoadIF_MT Interface between user program and tool management, contains
signals from/to Load/Unload magazine (multitool).
DB1072 TMSpindleIF_MT Interface between user program and tool management, contains
signals for spindle as change position (multitool).
DB1073 TMRevIF_MT Interface between user program and tool management, contains
signals for turret (multitool).
4.1.5 Blocks with user-specific adaptations
In the following, you will find a list of all of the blocks of the SINUMERIK PLC basic program
which always require user-specific adaptations and therefore cannot be automatically
upgraded. These blocks are therefore not contained in the master copy "840D sl PLC Basic
Program (upgrade)".
Table 4-6
Blocks with user-specific adaptations
Block type Address Icon Remark
Organization block OB1 OB1 Organization blocks are not available in the "840D sl PLC
Basic
Program (upgrade)" master copy due to the necessa‐
ry user-specific calls.
You can copy these blocks individually as needed from the
"840D sl PLC Basic Program" master copy and then import
your adaptations into the newly copied blocks.
OB40 OB40
OB82 OB82
OB86 OB86
OB100 OB100
Function block FB29 Diagnostics ...
Function FC12 FC12 ...
Data block DB2 ALMSG_DB Comment: The master copy "840D sl PLC Basic Program
(upgrade)"
contains the version "ExtendAlMsg = False", not
the version "ExtendAlMsg = True".
DB4 DB4 ...
DB5 DB5 ...
Programming the PLC
4.1 General information about the PLC program
SINUMERIK STEP 7 Toolbox V15.1
Configuration Manual, 12/2018, A5E46279635B AA 65
