3.6.2 Available SINUMERIK archive types
There are different types of archives which you can create in different ways. Essentially, you
cannot
use the TIA Portal to create archives that contain NC, drive or HMI data. However, you
can save a finely granular selection of translated program blocks as an archive in the TIA Portal
with the "PLC reload archive".
Archive type Command in the TIA
Portal
Command in SINU‐
MERIK Operate
Data contained
NCU commissioning ar‐
chive
- Softkey "Commission‐
ing
archive", option but‐
ton "Create commis‐
sioning archive"
The contained data can be configured as fol‐
lows in the dialog:
● NC data
– With or without compensation data
– With or without compile cycles
● PLC data (all or none)
● Drive data (ACX format or ASCII format)
● HMI data (all HMI data or a configurable
selection)
PLC commissioning ar‐
chive
(Page 50)
Hardware and all pro‐
gram blocks...
Softkey "Commission‐
ing archive", option but‐
ton "Create commis‐
sioning archive"; only
enable "PLC data" in
the dialog
● Hardware data (SDB) of the PLC
● Program blocks of the PLC
● Hardware data (SDB) of the CP
PLC hardware upgrade
archive
(Page 48)
Only hardware... Softkey "Commission‐
ing archive", option but‐
ton "Create PLC hard‐
ware upgrade archive
(only SDBs)"
● Hardware data (SDB) of the PLC
● Hardware data (SDB) of the CP
PLC reload archive
(Page
52)
Selected program
blocks...
-
● Program blocks of the PLC
(configurable in the dialog)
Complete archive
-
<Ctrl> + <Alt> + S
All data (not configurable)
Original status archive - Softkey "Commission‐
ing
archive", option but‐
ton "Create archive
original status"
Original status (factory setting) of all subcom‐
ponents or a selection of specific subcompo‐
nents and data (configurable in the dialog)
Configuring the NCU
3.6 Creating SINUMERIK PLC archives
SINUMERIK STEP 7 Toolbox V15.1
Configuration Manual, 12/2018, A5E46279635B AA 47
