Note
Distinguishing between TIA Portal project archives and SINUMERIK archives
SINUMERIK archives (*.zap14) have nothing in common with TIA Portal project archives
(*.arc):
● SINUMERIK archives contain precompiled commissioning data that you can import directly
to the NCU.
● TIA Portal project archives are compressed files, each of which contains a complete project,
including the complete folder structure of the project.
See: TIA Portal online help, search term "TIA Portal project archive".
3.6.3 External tools for SINUMERIK archives
Overview
Various tools are available to open and edit the created SINUMERIK archives:
Tool Purpose Available from
SinuCom ARC Editing of SINUMERIK archives SinuCom commissioning/service tools
in the SIEMENS Industry Mall (https://
eb.automation.siemens.com/
mall/en/us/Catalog/Product/
6FC5250-7AY00-7AG0)
Create MyConfig Extensive software, including functions
such as:
● Data comparison of SINUMERIK
archives
● Manipulation of SINAMICS data in
drive archives
● Creation of a SINAMICS archive
with defined topology
Create MyConfig in the SIEMENS In‐
dustry Mall (https://
eb.automation.siemens.com/
mall/en/us/Catalog/Products/
10167653)
3.6.4 Creating a PLC hardware upgrade archive
Requirement
● The
data carrier to be used or storage location is available and has sufficient storage space.
Configuring the NCU
3.6 Creating SINUMERIK PLC archives
SINUMERIK STEP 7 Toolbox V15.1
48 Configuration Manual, 12/2018, A5E46279635B AA
