Drive Telegram type I/O address Machine data
Standard addressing
schematic
Optimized addressing
schematic
Drive_Axis_6 SIEMENS telegram 136 4540 14750 13050[11]
Drive_CU_1 SIEMENS telegram 390 6530 15230
Infeed_1 SIEMENS telegram 370 6534 15280
Table 6-10 NX on DRIVE-CLiQ socket X104; DP address 14: I/O addresses of PROFIdrive telegrams
Drive Telegram type I/O address Machine data
Standard addressing
schematic
Optimized addressing
schematic
Drive_Axis_1 SIEMENS telegram 136 4580 14600 13050[12]
Drive_Axis_2 SIEMENS telegram 136 4620 14520 13050[13]
Drive_Axis_3 SIEMENS telegram 136 4660 14440 13050[14]
Drive_Axis_4 SIEMENS telegram 136 4700 14360 13050[15]
Drive_Axis_5 SIEMENS telegram 136 4740 14280 13050[16]
Drive_Axis_6 SIEMENS telegram 136 4780 14200 13050[17]
Drive_CU_1 SIEMENS telegram 390 6560 14680
Infeed_1 SIEMENS telegram 370 6554 14730
Table 6-11 NX on DRIVE-CLiQ socket X103; DP address 13: I/O addresses of PROFIdrive telegrams
Drive Telegram type I/O address Machine data
Standard addressing
schematic
Optimized addressing
schematic
Drive_Axis_1 SIEMENS telegram 136 4820 14050 13050[18]
Drive_Axis_2 SIEMENS telegram 136 4860 13970 13050[19]
Drive_Axis_3 SIEMENS telegram 136 4900 13890 13050[20]
Drive_Axis_4 SIEMENS telegram 136 4940 13810 13050[21]
Drive_Axis_5 SIEMENS telegram 136 4980 13730 13050[22]
Drive_Axis_6 SIEMENS telegram 136 5020 13650 13050[23]
Drive_CU_1 SIEMENS telegram 390 6590 14130
Infeed_1 SIEMENS telegram 370 6574 14180
Table 6-12 NX on DRIVE-CLiQ socket X102; DP address 12: I/O addresses of PROFIdrive telegrams
Drive Telegram type I/O address Machine data
Standard addressing
schematic
Optimized addressing
schematic
Drive_Axis_1 SIEMENS telegram 136 5060 13500 13050[24]
Drive_Axis_2 SIEMENS telegram 136 5100 13420 13050[25]
Drive_Axis_3 SIEMENS telegram 136 5140 13340 13050[26]
Drive_Axis_4 SIEMENS telegram 136 5180 13260 13050[27]
Drive_Axis_5 SIEMENS telegram 136 5220 13180 13050[28]
Drive_Axis_6 SIEMENS telegram 136 5260 13100 13050[29]
Configuring telegrams and drive units
6.8 Adapting I/O start addresses
SINUMERIK STEP 7 Toolbox V15.1
Configuration Manual, 12/2018, A5E46279635B AA 135
