Therefore, observe the following documentation prior to configuring Safety Integrated plus (F-
PLC):
● SIMATIC Safety - Configuring and Programming
● SIMATIC Safety - Getting Started
Note
Validity and scope of the information about SIMATIC STEP 7 Safety
This handling overview provided as example only serves as an introduction to configuring and
programming of SIMATIC STEP 7 Safety with SINUMERIK in the TIA Portal. It cannot always
be used for effective regular operation.
The following documentation is the main source of all information regarding functional safety
relating to configuring and programming in the TIA Portal:
● SIMATIC Safety
This also applies in the case of discrepancies between this manual and the SIMATIC STEP 7
Safety manual.
The warnings and other notes contained in that manual must be observed, even when they are
not repeated in this document!
WARNING
Danger to life if the safety instructions and residual risks are not observed
If the safety instructions and residual risks in the associated software and hardware
documentation are not observed, accidents involving severe injuries or death can occur - and
machines and equipment could be damaged.
● Observe the safety instructions given in the documentation on SINUMERIK Safety
Integrated plus, SIMATIC STEP 7 Safety and SINAMICS S120 Safety.
● Observe the safety instructions provided in the hardware documentation.
● When evaluating the risks, take into account residual risks.
Note
Compliance with applicable standards and regulations
Depending on the application area, the SINUMERIK NCU, being part of plants and systems,
requires that special standards and regulations be carefully observed. It is absolutely crucial
that you observe the appropriate safety and accident prevention regulations, e.g. IEC 60204-1
(general requirements placed on the safety of machines).
Requirement
● The "SIMATIC STEP 7 Safety Advanced" option package has been installed and licensed.
● A project is created in the TIA Portal and an NCU added.
Safety configuration
10.8 Configuring Safety Integrated plus (F-PLC)
SINUMERIK STEP 7 Toolbox V15.1
Configuration Manual, 12/2018, A5E46279635B AA 203
