Software
7
U24802-J-Z146-2-7600 RM400 C Models 95
Dokuschablonen Version 3.2 vom 25.10.93 © Siemens Nixdorf Informationssysteme AG 1993
Druck vom 12. 04.1999 16:17.23 Pfad: H:\Christoph\Manuale\PDF\RM\RM400C Betriebsanleitung\englisch\rm400.k07
Proceed as follows:
Ê Fill in the form.
Ê Save the values by pressing the
[SAVE] function key.
You then return to the X Server Administration window. You can now proceed as
follows, depending on whether you want to configure the Startup and Extended
parameters:
Ê To terminate the configuration of the X Server:
Press the
[EXIT] function key. Then move on to the section “Checking the test
screen” on page 98.
or
Ê Choose the menu item Startup.
Monitor Type Press the [CHOICES] function key and select a monitor type.
A selection list is then displayed, from which you can select a
monitor type. The preferred models appear at the top of the
list. If your monitor does not feature in this list, please refer to
the manual for your monitor in order to find out the range of
horizontal frequencies that your monitor can synchronize.
Then choose one of the “multifrequency“ entries that suits
best. b/w stands for “black-white“ or “monochrome“.
Graphics Mode Press the
[CHOICES] function key and select a mode.
A mode is a compilation of several parameters:
– resolution (height and width of the visible image in
pixels),
– depth (number of bits per pixel),
– vertical refresh rate in Hertz.
We recommend the following resolution, depending on the
size of the monitor:
33 cm (14") monitor: 640x480
35 cm (15") monitor: 800x600
40 cm (17") monitor: 1024x768
50 cm (21") monitor: 1280x1024
