Siemens SIMATIC ET 200SP Operating Instructions

Symbol Standard Marking
→ CE approval
Explosion protection in accordance with c-
UL-us (USA/Canada)
ANSI / ISA 12.12.01
CSA C22.2 No. 213-M1987
CL. I, Div. 2 GP.A.B.C.D T.. T4
CL. I, Zone 2, GP. IIC, T.. T4
Report no.: E239877
Explosion protection in accordance with
ATEX
DEKRA 19ATEX0094 X
EN IEC 60079-0 : 2018
EN 60079-7 : 2015 + A1 : 2018
II 3 G Ex ec IIC T.. Gc
Explosion protection in accordance with IE‐
CEx
DEK 19.0054X
IEC 60079-0 : 2017 (Ed.7)
IEC 60079-7 : 2015 (Ed.5.1)
Ex ec IIC T.. Gc
→ EAC certificate, available soon
→ Tick mark for Australia and New Zealand
→ KCC approval
→ The electronic weighing system is RoHS-compliant
according to EU Directive 2016/65/EU
Technical data
10.12 Certificates and approvals
Technology module TM SIWAREX WP351 HF
158 Operating Instructions, 01/2020, A5E47521010-AA

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
