Table 6-1 Example parameter table
DR Parameter S7 name Type Min.
value
Max.
value
Modbus ad‐
dress
Write pro‐
tection
Access
4 Calibration dig‐
its 0
(calculated)
calibrationDigits0calculated DINT 0 - 1200 x r
6.2 TIA Portal user program
6.2.1 Commissioning the electronic weighing system with TIA Portal
Procedure
1. Download the "Ready to use" TIA Portal example project for the technology module TM
SIWAREX WP351 HF (
https://support.industry.siemens.com/cs/ww/en/ps/17781/dl) from
the Internet.
The example project must be compatible with your SIMATIC controller.
2. Navigate to the electronic weighing system in the hardware catalog task card: Technology
modules > Weighing > SIWAREX > TM SIWAREX WP351 HF.
3. Drag-and-drop the electronic weighing system in the ET 200SP rack.
4. Click on the "General" sub-tab in the "Properties" tab.
Parameter assignment/addressing
6.2 TIA Portal user program
Technology module TM SIWAREX WP351 HF
38 Operating Instructions, 01/2020, A5E47521010-AA

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
