Siemens SIMATIC ET 200SP Operating Instructions

I/O process value Selection code
Last net process weight 13
Last net weight [lastNetWeight] 14
Totalizer 2 15
Youngest protocol ID 16
Current dosing step / Number of dosings in continuous mode 17
Load cell impedance 19
Load cell signal voltage 20
Load cell sense voltage 21
Current fine weight 22
Current trailing weight 23
Current shut-off correction value 24
Remaining amount to be loaded 25
Total set point 26
Weighing cycle progress 27
Tolerance limit TH2 (weight unit) 28
Tolerance limit TH1 (weight unit) 29
Tolerance limit TL1 (weight unit) 30
Tolerance limit TL2 (weight unit) 31
Material flow rate 32
Totalizer 1 (high fraction) 33
Totalizer 1 (low fraction) 34
Current fine signal time 35
Operating error / Technology messages (Word 1) 39
Technology messages (Word 2-+3) 40
Data/operating error (Word 1) / Additional information 41
Data/operating error (Word 2+3) 42
Temperature internal / external 43
6.9.16 I/O process values 5 to 8 [ioProcessValue5 to ioProcessValue8]
You can transfer up to four selectable process values from the CPU to the electronic weighing
system cyclically via the I/O. The following process values can be selected:
Selection code [ioProcessValue5 to ioPro‐
cessValue8]
Process values
0 Preset tare
1 Simulation weight
2 Weight offset
3 Weight correction factor
Parameter assignment/addressing
6.9 DR07 Interface parameters
Technology module TM SIWAREX WP351 HF
Operating Instructions, 01/2020, A5E47521010-AA 77

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
