6.8 DR06 Configuration of limits
6.8.1 Reference (limits 1 and 2) [limitReference]
Defines the weight to which the limits 1 and 2 relate and the interpretation of the ON/OFF values.
Selection code Interpretation of the ON/OFF values for limit 1 and lim‐
it 2 [limit1On] [limit2On] [limit1Off] [limit2Off]
Reference weight
0 (default) % - in relation to maximum weighing range Gross
1 % - in relation to maximum weighing range Net
4 Absolute - in relation to maximum weighing range Gross
5 Absolute - in relation to maximum weighing range Net
Limit 1 and 2 ON value [limit1On] [limit2On]
Limit 1 and 2 OFF value [limit1Off] [limit2Off]
The ON/OFF values are interpreted depending on the set reference value.
For a percentage-based interpretation of limits, specify values between -200.0 and 200.0.
For an absolute interpretation, specify the ON/OFF values as absolute weight values.
6.8.2 Limit 3 - empty [emptyLimit]
This parameter defines the time starting from which the scale is empty. The unit is expressed
either as a percentage of the maximum weight or in the weight unit depending on the "Limit
reference" setting
Reference (limit 3 - empty) [emptyLimitReference]
Defines the weight to which limit 3 - empty [emptyLimit] relates and the interpretation of the limit
value.
Selection code Interpretation of Limit 3 - empty [emptyLimit] Reference weight
2 (default) % - in relation to maximum weighing range Gross
3 % - in relation to maximum weighing range Net
4 Absolute - in relation to maximum weighing range Gross
5 Absolute - in relation to maximum weighing range Net
Parameter assignment/addressing
6.8 DR06 Configuration of limits
Technology module TM SIWAREX WP351 HF
Operating Instructions, 01/2020, A5E47521010-AA 71
