Maintaining and servicing your device
7.4 Removing and installing hardware
SIMATIC IPC677E
108 Operating Instructions, 04/2019, A5E45117996-AA
4. Install the new processor on the socket, as shown in the figure.
During positioning, make sure to take the highlighted arrow on the processor into
consideration.
5. Tilt the lever to the front again. Make sure that the bay covers the screw.
6. Press the lever all the way down and lock it again.
Damage to the processor due to excessive force
The locking mechanism may be stuck. The locking mechanism is damaged while being
pressed down.
The processor is not correctly locked in place by the bay. The result may be
malfunctions.
• Do not use excessive force.
• Tilt the lever back again and try again.
See also
Contacts (http://www.siemens.com/automation/partner)
SIMATIC IPC after-sales information system (http://www.siemens.com/asis)
