SIMATIC IPC677E
Operating Instructions, 04/2019, A5E45117996-AA
111
Technical specifications
8
8.1 Applicability of technical specifications
Note
The following technical specifications only apply under the following conditions:
•
The device is in good working order.
•
The device is closed.
•
The I/O
devices fulfill the requirements for the respective area of application (interference
emission according to EN 61000-6-4 / IEC 61000-6-
4, interference immunity according to
EN 61000-6-2 / IEC 61000-6-2).
8.2 General technical specifications
See the note in "Applicability of technical specifications (Page 111)".
Article numbers 6AV7261-.....-.... (for details, refer to the ordering documenta-
tion)
Dimensions IPC677E
(W x H x D in mm)
19"
22"
24"
464 x 294
529 x 331
585 x 363
Weight
19"
22"
24"
9.5 kg
10.5 kg
12.5 kg
Supply voltage AC Nominal 100 V AC to 240 V AC (-15% / +10%) (wide range)
Supply voltage DC
1
Nominal 24 V DC (-20% / +20%), SELV
1
Input current AC
Continuous current up to 2.5 A (up to 50 A for 1 ms at startup)
Input current DC
Continuous current up to 8 A (up to 14 A for 20 ms at startup)
Line voltage frequency
50 Hz to 60 Hz (47 Hz to 63 Hz)
Short-term voltage interruption in
accordance with Namur
max. 20 ms (at 93 to 264 V)
(max. 10 events per hour; recovery time at least 1 s)
Max. power consumption AC and DC Active power 176 W
Degree of protection
IP20 - Front when installed IP65 according to IEC 60529
Protection class
Protection class I to IEC 61140
Safety specifications
• IEC 61010-2-201
• EN 61010-2-201
• UL 61010-2-201
• CSA C22.2 No. 61010-2-201
