Technical specifications
8.6 Technical specifications of the drives
SIMATIC IPC677E
116 Operating Instructions, 04/2019, A5E45117996-AA
8.6 Technical specifications of the drives
See the note in "Applicability of technical specifications (Page 111)".
Hard disk drive
2.5" SATA HDD, ≥ 320 GB
Solid State Disk 2.5" SATA SSD, ≥ 480 GB standard
M.2 NVMe SSD 480 GB,
4x PCIe 3.0, form factor 22 mm x 80 mm, Type M
8.7 Technical specifications of the motherboard
See the note in "Applicability of technical specifications (Page 111)".
Chipset
Intel C246
Processor
Intel® Celeron® G4900 2 cores/2 threads,
3.1 GHz, 2 MB cache, VT
Intel® Core™ i3-8100 4 cores/4 threads,
3.6 GHz, 6 MB cache, VT
Intel® Core™ i7-8700 6 cores/12 threads,
3.2 (4.6) GHz, 12 MB cache, VT, iAMT
Main memory Expansion options:
4 up to 64 GB, DDR4 SDRAM, equipment see ordering docu-
mentation
Buffer memory
512 KB NVRAM
Expansion slots
Maximum 2 expansion slots
Maximum bandwidth of PCI slots
Rev. 2.3: 133 Mbps
Maximum bandwidth of PCI slots
Rev. 3.0: 8 GT/s (985 Mbps) bandwidth per lane
Max. permissible power loss per
slot
Total power consumption (all voltages) may not exceed 25 W.
Expansion card slots
Expansion card slots
(bus module 2 x PCI)
Slot 1
PCI: Specification Rev. 2.3, length: Max. 185 mm
Slot 2
PCI: Specification Rev. 2.3, length: Max. 185 mm
Expansion card slots
(bus module 1 x PCI and 1 x PCIexpress (x16))
Slot 1
PCI: Specification Rev. 2.3, length: Max. 185 mm
Slot 2
PCIexpress x16: Specification Rev. 3.0, length: Max. 185 mm
Expansion card slots
(bus module 2 x PCIexpress (x16, x4))
Slot 1
PCIexpress x4: Specification Rev. 3.0, length: max. 185 mm
Slot 2
PCIexpress x16: Specification Rev. 3.0, length: max. 185 mm
