Siemens SIMATIC IPC677E - Changing Internal Hard Disk Drive

Expanding the device and assigning device parameters
6.4 Drives
SIMATIC IPC677E
84 Operating Instructions, 04/2019, A5E45117996-AA
6.4.3 Changing internal hard disk drive
Requirement
● The device is disconnected from the mains and all connecting cables have been
removed.
● The device is open, see important information regarding this under Opening the Device
(Page 71).
● An original spare part, that is a hard disk drive of the same type, see information under
Accessories: Hardware (Page 22).
Procedure - Removal
1. Remove the marked screws and place the hard disk drive on its side.
2. Remove the marked screws and the drive carrier.
