Page #50 background image
Mounting and connecting the device
3.3 Connecting the device
SIMATIC IPC677E
50 Operating Instructions, 04/2019, A5E45117996-AA
3.3.3.2 Connecting the 24 VDC power supply
WARNING
Safety regulations- connecting cable
Use only AC or DC connecting cables which comply with the local safety regulations.
Otherwise, there is a risk of fire and electric shock. This can result in personal injury or
property damage.
Ensure that the AC or DC connecting cables comply with the safety regulations of the
country in which the device is installed and bear the marks required in each case.
Connect the protective conductor in accordance with the operating instructions.
WARNING
Risk of electric shock
The on/off button and on/off switch do not fully disconnect the device from the mains.
There is also a risk of fire if the device or connecting lines are damaged.
Always fully disconnect the device from the line voltage before performing work on the
device or when the device will not be used over an extended period of time.
For control cabinet mounting: Use an easily accessible central disconnect switch as
near as possible to the device and connect the device to a protective conductor.
When you install the device, make sure that the power supply connector is easily
accessible.
Note
Safety extra-low voltage (SELV)
The device must only be connected to a 24 V DC power supply which meets the
requirements of safe extra-low voltage (SELV) according to IEC/EN/DIN EN 60950-1.
A protective conductor must also be used.
The conductors must withstand the short-circuit current of the 24 V DC power source, so
that a short-circuit will not damage the cable.
Only connect cables with a minimum cross-section of 1.3 mm
2
(AWG16) and a maximum
cross-section of 3.3 mm
2
(AWG12).
