Mounting and connecting the device
3.2 Mounting the device
SIMATIC IPC677E
42 Operating Instructions, 04/2019, A5E45117996-AA
See also
Ambient conditions (Page 115)
Mounting positions (Page 37)
3.2.2 Mounting the device with mounting clips
Positions of the mounting clips
To achieve the degree of protection for the device, the positions for the mounting clips
shown below must be adhered to.
Requirement
● All packaging components and protective films have been removed from the device.
● To install the device, you need the mounting clips from the accessory kit.
● The mounting seal on the front of the device is not managed.
Procedure
Note
If the mounting seal is damaged or protrudes from the device, the guaranteed degree of
protection is not ensured.
It is prohibited from mounting the device if the mount
ing seal is damaged.
