Siemens SIMATIC IPC677E User Manual

Technical specifications
8.3 Current/power consumption and power supply
SIMATIC IPC677E
114 Operating Instructions, 04/2019, A5E45117996-AA
8.3.2 Technical specifications AC power supply (AC)
Technical specifications
Note
The power supply contains an active PFC (Power Factor Correction) circuit to conform to the
EMC guidelines.
Uninterruptible AC power
systems (UPS) must supply a sinusoidal output voltage in the
normal and buffered mode when used with SIMATIC PCs with an active PFC.
UPS characteristics are described and classified in the standards EN 50091
-3 and
IEC
62040-3. Devices with sinusoidal output voltage in the normal and buffered mode are
identified with the classification "VFI
-SS-...." or "VI-SS-....".
Power supply characteristics
AC power supply
Input data
Voltage
Nominal 100 - 240 V AC (-15% / +10%), wide range
Frequency
Nominal 50 Hz to 60 Hz (min. 47 Hz to max. 63 Hz), sinusoidal
Continuous current
Max. 2.5 A
Starting current (load-
independent)
to 50 A for 1 ms
Active power
176 W
Apparent power
190 VA
Output data
Voltages
+12 V / 12.5 A
Secondary power output
Max. 150 W
8.3.3 Technical specifications of direct voltage power supply (DC)
Technical specifications
Power supply characteristics
DC power supply
Input data
Voltage
Nominal 24 V DC (-20% / +20%), SELV, isolated
Continuous current
Max. 8 A
Starting current (load-
independent)
up to 14 A for 20 ms
Active power
176 W
Output data
Voltages
+12 V / 12.5 A
Secondary power output
Max. 150 W
