Technical specifications
8.9 Technical specifications of the interfaces
SIMATIC IPC677E
118 Operating Instructions, 04/2019, A5E45117996-AA
USB
4 × USB 3.1, type A, high current, backward compatible
2 × USB 3.1, type C, high current, backward compatible
Ethernet
1
3 × Ethernet ports (RJ45), 10/100/1000 Mbp
• 1 x Ethernet 1: Intel® Jacksonville i219-LM; AMT-capable
4
• 2 x Ethernet 2, 3: Intel® Springville i210-AT
Wake on LAN, Remote Boot and the following Teaming modes are
supported:
• Adapter Fault Tolerance (AFT)
• Adaptive Load Balancing (ALB)
• IEEE 802.3ad Dynamic Link Aggregation (DLA)
• Static Link Aggregation (SLA)
• Switch Fault Tolerance (SFT)
RS232, 115 kbps max., 9-pin SUB-D, male
Free slots for expansion
cards (see Motherboard
Versions with 2 and 5 PCI(e) cards
For unique labeling, the Ethernet ports are numbered on the enclosure. The numbering by the
operating system can differ.
No teaming with AMT.
When using AMT, the interface X1P1 must be used for connection to remote maintenance.
4
An analog monitor can be used with an adapter cable (optional).
