Process interfacing via an automation system (PLC, PC)
9.4 Control with FB 79
SIMATIC MV500
Operating Instructions, 03/2021, C79000-G8976-C494-05
189
To edit this job, the following parameters must be set in the "Settings > Communication >
Use >
Connections" menu in the WBM:
Text: PROFINET IO
Output of the result string (except commands 4 and 5)
Controller: PROFINET IO
Interface for the "DISA", "SEL0 ... SEL3", "TRN", "RES", "IN_OP", "TRD", "RDY" signals
Table 9- 46 Parameters not interconnected with the block (static local data)
Parameter Declaration Data type Address
Default Description
X position of the center point of the code
relative to the center of the image. Normal-
ized to the full resolution for the current
Y position of the center point of the code
relative to the center of the image. Normal-
ized to the full resolution for the current
Rotation angle of the code center point
(angle between the axis of the optical read-
er and the surface of the code field)
Symbol contrast as class
(value valid if ≠ ' ')
Print growth as class
(value valid ≠ ' ')
Axial non-uniformity as class
(value valid if not equal to ' ')
(value valid, if ≠ ' ')
Note:
If a "ReadErr" occurs, the old result data is
retained because no new data is available.
Overall quality as class
(value valid, if ≠ ' ')
Symbol contrast as absolute value
(value valid, if ≠ "-1.0e+0")
Print growth as absolute value
(value valid, if ≠ "-1.0e+0")
Axial non-uniformity as absolute value
(value valid, if ≠ "-1.0e+0")
Unused error correction
(value valid, if ≠ "-1.0e+0")
