Technical data
11.5 Technical specifications of the floodlight (external)
SIMATIC MV500
Operating Instructions, 03/2021, C79000-G8976-C494-05
251
11.5 Technical specifications of the floodlight (external)
Table 11- 5 Technical specifications of the external floodlights for SIMATIC MV500
6GF3500-8DF30-xDA0
Product type designation
Floodlight MV500
Optical data
Lighting distance and irradiance
• 1DA0
0.0 m - 214.8 W/m²
0.1 m - 108.9 W/m²
0.2 m - 49.0 W/m²
0.5 m - 10.2 W/m²
• 2DA0
0.0 m - 312.9 W/m²
0.1 m - 164.6 W/m²
0.2 m - 83.7 W/m²
0.5 m - 19.4 W/m²
• 3DA0
0.0 m - 233.1 W/m²
0.1 m - 147.1 W/m²
0.2 m - 93.8 W/m²
0.5 m - 27.4 W/m²
Light color / wavelength
(relative luminosity 0.2 ... 1.0)
White / 6000 K
Operating mode
Permanent and switching operation
Irradiance
• 1DA0: 49 W/m² @ 0.2 m
• 2DA0: 84 W/m² @ 0.2 m
•
1DA0: 94 W/m² @ 0.2 m
Supply voltage, current consumption, power loss
Supply voltage
24 V DC (19 to 30 V DC)
Current consumption (at 24 V DC)
• 1DA0: 1.5 A
• 2DA0: 2.7 A
• 3DA0: 3.9 A
Max. electrical power at the light source
• 1DA0: 30 W
• 2DA0: 57 W
• 3DA0: 81 W
