Scope of delivery and ordering data
13.3 Accessories
SIMATIC MV500
Operating Instructions, 03/2021, C79000-G8976-C494-05
265
13.3.2 Built-in ring lights
Note
Achievement of IP67 protection
To achieve IP67 degree of protection, a protective lens barrel must be screwed on and all
interfaces must be closed by cable connections or protective caps.
If no protective lens barrel is used or the interfaces are closed, t
he reader only achieves IP20
Note
Compatibility of the built
-in ring lights for SIMATIC MV440
Note that SIMATIC MV440 built
-in ring lights are compatible with SIMATIC MV500 optical
readers. However, using the MV440
built-in ring lights on MV500 does not support the micro
SD card and E-focus function.
Table 13- 5 Built-in ring lights for SIMATIC MV500
Built-in ring light (red, basic) for
SIMATIC MV500
• Light source: LED red
(625 nm)
• Lighting distance up to 0.8 m
• Including anti-glare attachment
Built-in ring light (red, far) for
SIMATIC MV500
• Light source: LED red
(625 nm)
• Lighting distance up to 3.0 m
Including anti-glare attachment
Built-in ring light (red, multi) for
SIMATIC MV500
• Light source: LED red
(625 nm)
• Lighting distance up to 1.5 m
• including attachment with polarization
filter
• Including anti-glare attachment
Built-in ring light (white, multi) for
SIMATIC MV500
• Light source: LED white
(6500 K)
• Lighting distance up to 1.5 m
• including attachment with polarization
filter
Including anti-glare attachment
