Image processing
3.2 Code verification
SIMATIC MV500
68 Operating Instructions, 03/2021, C79000-G8976-C494-05
Note
Verification error
Whenever a verification error occurs, all quality grades are output as "E" and the error number
is output instead of the quality values. For information on the meaning of error numbers, see
the section "Read and verification error messages (Page 229)".
3.2.9.1 Standard report for ISO/IEC 16022 "Standard / ID-Genius" decoder
Table 3- 10 Output parameters: ISO/IEC 16022 "Standard" decoder
Field name (String input)
Value
Verification type (Qt)
4
If the exposure settings do not conform to the
standard or uncalibrated verification is active: E
Evaluation (Qs)
3 (Good), 2 (Fair), 1 (Poor)
Overall grade (Q0)
4 ... 0
Contrast grade (Q1)
4 ... 0
Contrast (q1)
0 ... 100
Axial non-uniformity grade (Q2)
4 ... 0
Axial non-uniformity (q2)
0.00 ... 1.00
Print growth grade (Q9)
4 ... 0
Print growth X (q9)
-100 ... 100
Print growth Y (q9)
-100 ... 100
Unused error correction grade (Q4)
4 ... 0
Unused error correction (q4)
0.00 ... 1.00
Cell size (q10)
0 to 99.9 mil
Uncalibrated verification: Output in pixels [px]
ECCLevel (q14)
200
Height (q15)
0 to 9.99 inches
Uncalibrated verification: Output in pixels [px]
Width (q16)
0 to 9.99 inches
Uncalibrated verification: Output in pixels [px]
Angle (q17)
0 ... 360°
