3.2.9.3 Standard report for ISO/IEC 29158
Table 3- 12 Output parameters: ISO/IEC 29158
Field name (String input)
Value
Verification type (Qt)
1
If the exposure settings do not conform to the
standard or uncalibrated verification is active: B
Evaluation (Qs)
3 (Good), 2 (Fair), 1 (Poor)
Overall grade (Q0)
4 ... 0
Reference decode grade (Q7)
4 ... 0
Cell contrast grade (Q1)
4 ... 0
Cell contrast (q1)
0 ... 100
Axial non-uniformity grade (Q2)
4 ... 0
Axial non-uniformity (q2)
0.00 ... 1.00
Grid non-uniformity grade (Q3)
4 ... 0
Grid non-uniformity (q3)
0.00 ... 1.00
Unused error correction grade (Q4)
4 ... 0
Unused error correction (q4)
0.00 ... 1.00
Grade L/F fixed pattern damage (Q5)
4 ... 0
Cell modulation grade (Q6)
4 ... 0
Minimum reflectance grade (Q8)
4 ... 0
Minimum reflectance (q8)
0 ... 100
Print growth X (q9)
-100 ... 100
Print growth Y (q9)
-100 ... 100
Cell size (q10)
0 to 99.9 mil
Uncalibrated verification: Output in pixels [px]
Current average gray scale value (q11)
0 ... 255
Aperture (q12)
0 ... 999
Percentage aperture (q13)
50, 80, 0
ECCLevel (q14)
200
Height (q15)
0 to 9.99 inches
Uncalibrated verification: Output in pixels [px]
Width (q16)
0 to 9.99 inches
Uncalibrated verification: Output in pixels [px]
Angle (q17)
0 ... 360°
